| Dimensions (L x W x H) | mm | 830 x 665 x 820 |
|---|---|---|
| Net weight | kg | 35.00 |
| Guarantee (+ request guarantee) | Years | 2 + 1 |
| Material | GRP Duroplast/stainless steel | |
| Number of inlets | Unit | 2 |
| Connection inlet | 1 x DN 185 + 2 x DN 110 | |
| Connection to | AquaMax Eco Gravity, Bitron Gravity, ProfiClear Classic | |
| Number of outlets | Unit | 3 |
| Connections, outlet | 1 x 2" / 2 x DN 110 | |
| Connections, sludge discharge | DN 75 | |
| Max. flow rate | l/h | 25000 |
| Type of use | Gravity fed system, Pump fed system | |
| Installation height above water level | cm | 10.5 |
| Other | Pollutant discharge incl. slide valve | |
| Item number | 42913 | |
| EAN | 4010052429137 |
