| Dimensions (L x W x H) | mm | 1200 x 800 x 760 |
|---|---|---|
| Rated voltage (primary, secondary) | 230 V / 50 Hz, 12 V / AC | |
| Power consumption | W | 5 |
| Cable length 12 V device (with power unit) | m | 2.10 (Power unit) + 5.00 |
| Net weight | kg | 105.00 |
| Guarantee (+ request guarantee) | Years | 2 + 1 |
| Number of filter foams, total | Unit | 18 |
| Number of blue filter foams | Unit | 4 |
| Number of red filter foams | Unit | 7 |
| Number of purple filter foams | Unit | 7 |
| Special filter granulate | kg | 14.50 |
| Temperature display | No | |
| Coarse debris extraction | µm | 300 |
| Connection inlet | mm | 25 / 32 / 38 / 50 |
| Connection inlet | 1", 1 ¼", 1 ½", 2" | |
| Connections, outlet | DN 110 | |
| Connections, sludge discharge | DN 75 | |
| Litres per hour, min. | l/h | 8000 |
| Max. flow rate | l/h | 17500 |
| Suitable for ponds up to max. | m³ | 140.0 |
| Suitable for ponds with fish stock | m³ | 70.0 |
| Suitable for ponds with koi | m³ | 35.0 |
| Connection to | Bitron C 36 - 110 W, Bitron Eco 120 - 240 W | |
| Item number | 57696 | |
| EAN | 4010052576961 |
