Dimensions (L x W x H) | mm | 1200 x 800 x 760 |
---|---|---|
Rated voltage (primary, secondary) | 230 V / 50 Hz, 12 V / AC | |
Power consumption | W | 5 |
Cable length 12 V device (with power unit) | m | 2.10 (Power unit) + 5.00 |
Net weight | kg | 105.00 |
Guarantee (+ request guarantee) | Years | 2 + 1 |
Number of filter foams, total | Unit | 18 |
Number of blue filter foams | Unit | 4 |
Number of red filter foams | Unit | 7 |
Number of purple filter foams | Unit | 7 |
Special filter granulate | kg | 14.50 |
Temperature display | No | |
Coarse debris extraction | µm | 300 |
Connection inlet | mm | 25 / 32 / 38 / 50 |
Connection inlet | 1", 1 ¼", 1 ½", 2" | |
Connections, outlet | DN 110 | |
Connections, sludge discharge | DN 75 | |
Litres per hour, min. | l/h | 8000 |
Max. flow rate | l/h | 17500 |
Suitable for ponds up to max. | m³ | 140.0 |
Suitable for ponds with fish stock | m³ | 70.0 |
Suitable for ponds with koi | m³ | 35.0 |
Connection to | Bitron C 36 - 110 W, Bitron Eco 120 - 240 W | |
Item number | 57696 | |
EAN | 4010052576961 |
